MC1000 Series

Emphasis on Easy to read

• Easy to read large LCD display
• Dual displays for measured data and arithmetic result
• Backlit LCD display enables to see under low-right intensity

Emphasis on Measurement

• Multi input (Thermocouple/RTD) allows various applications
• Calibration function is a standard provision
• Exclusive connector prevent to drop a probe

Abundant functions

• 20 data storage
• Various computation (Max, Min, Hold, Average, Alarm, Clock)
• 1000 hours battery life

Number Of Input: 1 point

Input Types:

Multiple range thermocouple: K, T

Resistance thermometer: Pt100

Measuring Range:

Thermocouple K: -200 to 1370°C

T: -200 to 400°C

Resistance thermometer Pt100: -200 to 500°C

Display Resolution:

1°C: -200 to 1370°C

0.1°C: -99.9 to 199.9°C (Manual setting)

Accuracy Rating: At resolution 1°C, ± (0.1%+1°C of
measured value)

At resolution 0.1, Thermocouple K, T ± (0.1%+0.5°C of
measured value)

Resistance thermometer Pt100 -99.9 to -0.1°C: ± (0.1%+0.3°C of measured value)

0.0 to 199.9°C: ± (0.1%+0.2°C of measured value)

*Ambient temperature 20 to 30°C, including thermocouple reference junction compensation accuracy.

Display: 3･1/2-digit LCD with backlight

Memory: Maximum 20 data

Calculation: Max/min/average/amount of change

Battery: AA alkaline battery 2 pcs.

Battery Life: 1000 hours (without backlight) 100 hours (with backlight ON)

Working Temperature Humidity: 0 to 50°C, 10 to 80%RH (no dew condensation)

Dimensions: W76×H164×D36.3mm

Weight: Approx. 250g
